SpinForm technology
Efficient stamping of large 2K components
Product information
Multi-component parts can be manufactured in a cost-effective manner using special swivel plate SpinForm technology if high cavities and quantities are needed. The two mold parting lines are ideal for compression molding two-component parts. SpinForm ensures a machine-side compression stroke, which is carried out separately for each component.
- Double production capacity with unchanged clamping force
- Ideal for particularly large components or particularly high quantities
- Excellent accessibility thanks to the cantilevered rotating unit with optional center plate
- Integration of special processes such as embossing possible
Mold technology
The SpinForm technology is suitable for all 2K components that are also suitable for rotary table technology.
Process technology:
The machine has two parting lines, allowing two molds to be clamped one behind the other. This creates two outlets: one parting line for the preform and a second parting line for the second component. The major advantage lies in the simultaneous injection of both components, which enables double output with the same clamping force compared to rotary table technology.
